C&I BESS SR-BLOCK200-MF
The product of SR-BLOCK200-MF is a power storage system specially designed for regional microgrids such as small CBDs, farms, islands, outdoor photovoltaic power stations, etc., which can fully guarantee the power demand and energy security in these scenarios.
Model: SR-BLOCK200-MF 100P
Battery Parameter
Battery Energy (kWh)0 215
Cell Type (Ah): LFP 280
Rated Voltage (V): 768
Voltage Range (V): 672-850
Rated Energy (kWh): 215-430AC Parameter
Rated Power (kVA): 100
Rated Voltage (V): 400
Voltage Range (V): 320-460
Rated Current(A): 144
Rated Frequency (Hz): 50/60
Over Power: 110%long time;120% 1minPV Parameter
Rated MPPT Quantity: 2
Rated MPPT Module Power (kW): 50
Max. Output Power (kW): 120
MPPT Voltage Range: 250-850V
MPPT Voltage Range @ full load (V): 450-850General Parameter
Max System Efficiency: ≥ 90%
IP Rating: Battery Cabinet: IP55 / Hybrid Inverter: IP54
Anticorrosion Grade: StandardC4
Cooling Method: Battery: HVAC / Hybrid Inverter: Forced air Cooling
Operating Temperature Range: -20-50℃
Operating Humidity: 0%-95%
Elevation (m): <2000
Firefighting System: Integrated
Communication Port: CAN, RS485, ETH
Multi-scenario
• Multifunctional integration, supporting PV and generator access, on grid to off-grid switching<20ms
Economical & Efficient
• High energy efficiency
• Pre-assembled, transportation of complete
• High-efficiency heat dissipation, increase battery life and system discharge capacity
Real-time monitoring and control
• 7*24h Real-time remote and local monitoring and control
• Intelligent early warning, regular automatic safety checks, and eliminationof hidden dangers
Flexible & Expandable
• Single unit 100-215kWh capacity
• Parallel MAX. up to 2MWh capacity battery
