C&I BESS SR-BOX200-DC
The C&I BESS SR-BOX200-DC system is a power storage system specially designed for regional microgrids such as small CBDs, farms, islands, outdoor photovoltaic power stations, etc., which can fully guarantee the power demand and energy security in these scenarios.
Model: SR-BOX200-DC
Battery Parameter
Battery Capacity (kWh): 215
Cell Type/V/Ah: LiFePO4 3.2/280
Rated Voltage (V): 768
Voltage Range (V): 672-864
Battery System Configuration: 1P240S
Charge and Discharge Rate ≤0.5P
Cooling Mode: Air cooling/3kW
AC On-grid Parameter
Rated Charge/Discharge Power (kW): 50
Rated Grid Voltage Range (V): 380-400
Applicable Grid Frequency (Hz): 50/60
MAX.. Output Current (A): 83
THDi: <3%
PV Parameter
MAX. Input Power (kW): 75
MPPT Voltage Range (V): 200~850
General Parameter
Dimension W*D*H (mm): 1412*1190*2339
Weight(T): 2.5
Firefighting System: Integrated/Aerosol
Communication Port: CAN, RS485, ETH
Multi-scenario
• Retrofit on-grid system to hybrid system
(energy storage)
Economical & Efficient
• High energy efficiency
• Pre-assembled, transportation of complete
• High-efficiency heat dissipation, increase battery life and system discharge capacity
Real-time monitoring and control
• 7*24h Real-time remote and local monitoring and control
• Intelligent early warning, regular automatic safety checks, and eliminationof hidden dangers
Flexible & Expandable
• DC-coupling. 24 MPPT inputs and 12 MPPT outputs
• Support matching one PV controller with multiple battery cabinets
