ESS SR-RACK-5KS
The Rack series ESS SR-RACK-5KS residential products are specially designed for residential applications by Sunred. It has several battery modules and each module has an integrated intelligent BMS, which offers great advantages in terms of safety, life cycle, energy density and temperature range.
Model: SR-RACK-5KS
Battery Parameter
Rated Voltage (V): 51.2
Rated Capacity (Ah): 100Rated Energy (Wh): 5120
Operation Parameter
Voltage Range (V): 44.8~56
Charge Voltage Range (V): 55.2~56
Cut-off Voltage (V): 44.8
Recommended Charge Current (A): 50
Max Charge Current (A): 100
Max Discharge Current (A): 100
Physical Parameter
Dimension - W*D*H (mm): 442*470*154
Weight (kg): 45
Communication Port: RS485、CAN
Display: LED + LCD
Terminal: M6Environment Parameter
Humidity (%): 5~95% RH
Charge Temperature Range (℃): 0~45
Discharge Temperature Range (℃): -20~55
Storage Temperature Range (℃): -20~45
Service Life
Cycle Life (Time): ＞6000 (0.5C@ 25℃，80% DOD）
Design Life (Year): 15
Certification
Safety & Certification: CE, IEC62619, UL1973, UL 9540A, UL9540
Transportation: UN38.3
Multi-scenario
• Multifunctional integration, supporting PV and generator access, on grid to off-grid switching<20ms
Economical & Efficient
• High energy efficiency
• Pre-assembled, transportation of complete
• High-efficiency heat dissipation, increase battery life and system discharge capacity
Real-time monitoring and control
• 7*24h Real-time remote and local monitoring and control
• Intelligent early warning, regular automatic safety checks, and eliminationof hidden dangers
Flexible & Expandable
• Single unit 100-215kWh capacity
• Parallel MAX. up to 2MWh capacity battery
